ECP-173W EcoPower WP173W Aluminum Digital Micro Winch Servo (HV) (Waterproof) w/Spool, Line and Hook

EcoPower WP173W Aluminum Digital Micro Winch Servo (HV) (Waterproof)

A micro digital steering servo, sealed against water for wet, muddy runs, high-voltage capable for more torque and speed on a 7.4–8.4 V BEC. Recommended for winches.

Specifications

• Brand: EcoPower
• Part number: ECP-173W
• Application: 1/24, 1/16 & 1/18
• Input Voltage: 6V-8.4V
• @6.0V: : 0.09 sec/60°
• @8.4V: : 0.07 sec/60°
• @6.0V: : 123oz.in (8.9Kg-cm)
• @8.4V: : 173oz.in (12.5Kg-cm)
• Motor: Digital Coreless
• Output Shaft: Mini 25T
• Shaft Diameter: 0.20in (5mm)
• Gear Material: Metal
• Dimensions (LxWxH): 0.9x0.47x1.25in (23x12x31.75mm)
• Winch Barrel Dimensions (WxH): 0.75x0.26in (19x6.5mm)
• Weight: 0.81oz (23g)

Features

• 360-degree continuous rotation
• Custom low-profile winch spool
• All-Steel internal gears
• Waterproof construction
• High-voltage compatible (up to 8.4V)
• Aluminum case
• Compact micro size
• Winch line and hook included
• Direct upgrade from EcoPower 173 platform
• Plug-and-Play installation

Includes

• (1) WP173W Aluminum Digital Micro Winch Servo
• (1) Aluminum Winch Horn
• (1) Winch Hook
• (1) Winch Line

GOOD TO KNOW

• We ship to your door, or you can pick it up at our Davie or Doral store.
• Ask us in store if you need help choosing the right part for your model.

Product Details

• UPC: 694485089188
