ECP-200T-TI EcoPower WP200T-TI Waterproof High Torque Titanium Gear Brushless Servo

EcoPower WP200T-TI Waterproof High Torque Titanium Gear Brushless Servo

A standard-size brushless titanium-gear steering servo, sealed against water for wet, muddy runs. Recommended for R/C cars and trucks. Torque: 467oz-in (34.2 kg-cm) @ 6.0V, 578oz-in (41.6 kg-cm) @ 8.4V. Speed: 0.11/60° sec @ 6.0V, 0.09/60° sec @ 8.4V.

Specifications

• Brand: EcoPower
• Part number: ECP-200T-TI
• Application: 1:10-1/8 Scale
• Operating Voltage: 6.0V - 8.4V
• Operating Temperature: 14° to 140° F (-10 to +60° C)
• Operating Speed @ 6.0V: 0.11/60° sec
• Operating Speed @ 8.4V: 0.09/60° sec
• Dynamic Torque @ 6.0V: 467oz-in (34.2 kg-cm)
• Dynamic Torque @ 8.4V: 578oz-in (41.6 kg-cm)
• Motor Type: Brushless Digital
• Output Shaft: 25T
• Gears: Titanium
• Weight: 61g
• Pulse/Frequency: 1520s / 333hz
• Dimensions: 40.2x20x48.5mm
• Length (Bottom to Mount): 27.5mm

Features

• Ideal for a 1/10 & 1/8 Bashing Platforms
• Brushless motor
• High voltage circuitry
• Titanium gears
• Aluminum middle black case
• Servo Hardware and grommets

Includes

• (1) WP200T-TI Waterproof High Torque Titanium Gear Brushless Servo
• (1) Aluminum clamping servo horn

GOOD TO KNOW

• We ship to your door, or you can pick it up at our Davie or Doral store.
• Ask us in store if you need help choosing the right part for your model.

Product Details

• UPC: 694485083698
