PTK-300LPT / PTK-160TBL 160TBL "Black Label" Low Profile High Torque Brushless Servo

ProTek RC 160TBL Black Label Low Profile High Torque Brushless Servo

Low Profile. High Torque. Pro-Level Precision.

The ProTek RC 160TBL delivers outstanding performance in a compact low-profile form, perfect for 1/10 to 1/8 scale race platforms. With its high-torque brushless motor, full aluminum case, and ultra-precise internals, this servo is built to meet the needs of pro drivers—and was even used by Ryan Maifield to win the 2019 ROAR 4WD Off-Road Nationals.

🔧 Key Features

• Low-profile design ideal for tight chassis layouts
• Brushless motor technology for better torque, longer lifespan, and efficient power delivery
• Full black anodized aluminum case with gold and silver accents for a premium look
• Heat-sink center section for improved thermal management
• Dual ball bearings and full metal gears for smooth, reliable performance
• 140mm servo lead with gold-plated connector
• Includes aluminum clamping single-arm horn + servo mounting washers

⚙️ Performance Specifications

• Operating Voltage: 4.8V – 7.4V
• Speed @ 6.0V: 0.08 sec/60°
• Speed @ 7.4V: 0.06 sec/60°
• Torque @ 6.0V: 230 oz-in (16.5 kg-cm)
• Torque @ 7.4V: 290 oz-in (20.9 kg-cm)
• Motor Type: Brushless
• Gear Type: Metal
• Output Shaft: 25T spline
• Pulse/Frequency: 1520μs / 333Hz

📐 Dimensions

• Size: 39.5 x 20 x 30.6 mm
• Bottom to Mounting Tabs: 19.35 mm
• Weight: 55g

⚠️ Important Note for Futaba Users

If using a Futaba transmitter, disable BLS mode unless using a Futaba BLS-type servo. BLS mode is not compatible with the 160TBL and may cause glitching or poor performance.

Now available at Goat Hobbies – low profile, high impact performance for the most demanding builds.

Trusted by champions. Built to win.

Product Details

• Brand: ProTek RC
• Part #: PTK-300LPT
• UPC: 694485097664

Pick up at Goat Hobbies in Davie or Doral, FL — or we ship it to you.
